S3000-8M2XF-PoE+ 8-Port 2.5G PoE+ Desktop Managed Switch
MODELS3000-8M2XF-PoE+
8x 2.5G PoE+ ports + 2x 10G SFP+ ports, compact desktop design
78W PoE budget, 802.3af/at compliant for APs & cameras
Fanless for zero noise, external DC power, quiet & flexible deployment
Full Layer 2 management (VLAN, Aggregation, QoS, ACL)
Designed for small high-performance offices, studios & dense device access in quiet spaces
GET A FREE QUOTE
HODONET S3000-8M2XF-PoE+ Product Specifications
*8-Port 2.5G PoE+ Desktop Managed Switch*
| Category | Item | Specification |
|---|---|---|
| Overview | Description | An ultra-compact desktop PoE+ managed switch featuring 8x 2.5G PoE ports and 2x 10G SFP+ uplinks. With a fanless silent design and external DC power, it serves as a high-performance, flexible network and power hub for small offices, creative studios, or any quiet environment. |
| Physical Specs | Performance | |
| • Switching Capacity | 80 Gbps | |
| • Forwarding Rate | 59.52 Mpps | |
| • MAC Address Table | 16K | |
| Hardware | ||
| • Flash Memory | 256 MB | |
| • DRAM | 2 GB | |
| Power | ||
| • Input | DC 12V, 1.5A | |
| • Power Consumption | 18 W | |
| Interface | Data Ports | 8 x 10/100/1000/2500Base-T PoE+ RJ45 Ports 2 x 10G SFP+ Fiber Ports |
| Management Ports | 1 x Console (RJ45) | |
| PoE | Standard | IEEE 802.3af/at |
| Total Power Budget | 78 W | |
| PoE Port Count | 8 Ports | |
| Software Features | System Management | SNMP, CLI, Web, SSH, DNS, ISDP, LLDP, Timer Schedule, PoE Management |
| Layer 2 Switching | VLAN (4K), STP/RSTP/MSTP, LACP (12 groups, up to 8 ports/group), Loop Protection, ERPS, Multicast, UDLD | |
| VLAN | Port-based VLAN, Voice VLAN, Protocol VLAN, GARP, 802.1Q Tunneling | |
| Quality of Service | 8 Queues per Port, Ingress/Egress Rate Limiting, Auto QoS, DiffServ | |
| Security | Port Authentication, ACL, Access Control, Traffic Control, DoS Protection | |
| Maintenance & Monitoring | sFlow, Port Mirroring, Logging, Configuration File Management, Upgrade | |
| Environmental | Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C | |
| Operating Humidity | 20% to 85% RH (Non-condensing) | |
| Storage Humidity | 5% to 95% RH (Non-condensing) | |
| Cooling | Fanless, Natural Convection | |
| Mechanical | Dimensions (D×W×H) | 218.4 mm × 145 mm × 27 mm |
| Weight | 0.7 kg |
