S4300-8G11XF 8x1Gb RJ45,11x10Gb SFP+ Managed Switch

MODELS4300-8G11XF

  • 8 GE RJ45 ports + 11 10GE SFP+ ports for hybrid connectivity

  • Complete Layer 2 management (VLAN, Aggregation, QoS, ACL)

  • Compact design, 36W power consumption with fan cooling

  • CLI & Web management for flexible and efficient configuration

  • Ideal for high-performance access, server aggregation & small backbone

GET A FREE QUOTE

Specifications Description

HODONET S4300-8G11XF Product Specifications

*8-Port Gigabit + 11-Port 10G SFP+ Managed Switch*

CategoryItemSpecification
OverviewDescriptionA hybrid aggregation switch featuring 8x 1G RJ45 ports and 11x 10G SFP+ fiber ports. Designed for connecting a mix of gigabit devices and high-speed servers or storage, serving as a cost-effective aggregation or core switch in small to medium-sized networks.
Physical SpecsPerformance• Switching Capacity: 236 Gbps
• Throughput: 175.58 Mpps
• MAC Address Table: 32K

Hardware• Flash Memory: 256 MB
• DRAM: 4 GB
InterfaceData Ports8 x 10/100/1000Base-T RJ45 Ports
11 x 10G SFP+ Fiber Ports

Management Port1 x Console Port (RJ-45)
Power & CoolingPower InputAC 100~240V, 50/60Hz

Power Consumption36 W

CoolingForced-Air Cooling (with Fans)
EnvironmentalOperating Temperature0°C to 40°C

Storage Temperature-20°C to 70°C

Operating Humidity20% to 85% RH (Non-condensing)

Storage Humidity5% to 95% RH (Non-condensing)
MechanicalDimensions (W×H×D)440 mm × 44 mm (1U) × 280 mm

Weight3.8 kg
Software & Protocol FeaturesSystem ManagementSNMP, CLI, Web GUI, SSH, DNS, LLDP, ISDP, Timer Schedule, DeviceView

Layer 2 SwitchingVLAN (4K), STP/RSTP/MSTP, LACP (12 groups, up to 8 ports/group), Loop Protection, Multicast, UDLD

VLANPort-based VLAN, Voice VLAN, Protocol VLAN, GARP, 802.1Q-in-Q Tunneling

Quality of Service (QoS)8 Queues per Port, Ingress/Egress Rate Limiting, Auto QoS, 802.1p/DSCP Priority, DiffServ

SecurityPort Security (802.1X), ACL (IP/MAC/Port), Access Control, DoS Protection, Management Security

Maintenance & MonitoringsFlow, Port Mirroring, Syslog, Configuration Backup/Restore, Firmware Upgrade, Diagnostics


HODONET S4300-8G11XF, 8-Port Gigabit + 11-Port 10Gigabit SFP+ Layer 2 Managed SwitchThe HODONET S4300-8G11XF is a hybrid-port managed switch designed for enterprise networks requiring high bandwidth and flexible connectivity. It uniquely combines 8 auto-negotiating 10/100/1000Base-T Gigabit Ethernet ports with 11 10G Base-R SFP+ fiber ports, enabling connection to both conventional end-devices and high-speed fiber uplinks or servers. This makes it an ideal solution for building high-performance access layers or compact aggregation layers. The switch is equipped with a comprehensive suite of Layer 2 management features, including 4K VLAN, Link Aggregation (LACP), Quality of Service (QoS), Access Control Lists (ACL), and port security, all configurable via CLI or an intuitive Web interface for granular control. Despite its powerful performance, it consumes only 36W of power and ensures stable thermal management with a compact 1U rack-mountable design and built-in fans. With its excellent cost-performance ratio and flexible port configuration, the S4300-8G11XF is perfectly suited for scenarios such as server access in enterprise data centers, core aggregation for campus networks, or video production networks.
