S1200-50G 50x1Gb RJ45 Switch
MODELS1200-50G
50 GE RJ45 ports, plug-and-play, no configuration
Fanless & quiet design, only 36W power consumption
Supports 16K MAC address & 9K jumbo frames
IP30 rating & wall-mounting for flexible deployment
Fully compliant with IEEE Ethernet standards
GET A FREE QUOTE
HODONET S1200-50G Product Specifications
*50-Port Gigabit Unmanaged Switch*
| Category | Item | Specification |
|---|---|---|
| Overview | Description | A high-density, fanless unmanaged switch featuring 50x Gigabit RJ45 ports. Designed for plug-and-play deployment in environments requiring extensive device connectivity, such as offices, classrooms, or digital signage networks, with silent and energy-efficient operation. |
| Physical Specs | Performance | • Switching Capacity: 100 Gbps • Throughput: 74.4 Mpps • MAC Address Table: 16K • Jumbo Frame: 9K |
| Hardware | • Memory: 8 Mbit | |
| Interface | Data Ports | 50 x 10/100/1000Base-T RJ45 Ports |
| LED Indicators | Ports 1-50: Link/Act (Green); Speed: 100M (Green) / 1000M (Green) | |
| Switch Function | 50-Port Gigabit Unmanaged Switching | |
| Power | Input | AC 100~240V, 50/60Hz |
| Power Consumption | 36 W | |
| Design | Cooling | Fanless, Natural Convection |
| Mounting | Wall Mount | |
| Protection Rating | IP30 | |
| Standards | Network | IEEE 802.3, 802.3u, 802.3ab, 802.3x |
| EMC | Class B | |
| Environmental | Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C | |
| Operating Humidity | 5% to 85% RH (Non-condensing) | |
| Storage Humidity | 5% to 95% RH (Non-condensing) | |
| Mechanical | Dimensions (D×W×H) | 440 mm × 44 mm × 210 mm |
| Weight | 1.35 kg |
