S3000-24M6XF-PoE++ 24x2.5Gb RJ45, 6x10Gb SFP+, Managed PoE++ Switch

MODELS3600-24M6XF-PoE++

  • 24x 2.5G PoE++ ports (last 8 ports up to 60W/port) + 6x 10G SFP+ ports

  • 370W high PoE++ budget, 802.3af/at/bt compliant for high-power devices

  • Full Layer 2 management (VLAN, Aggregation, QoS, ACL)

  • High performance & fan cooling for stable high-density, high-power operation

  • Designed for high-power APs, PTZ cameras, industrial equipment

GET A FREE QUOTE

Specifications Description

HODONET S3000-24M6XF-PoE++ Product Specifications
*24-Port 2.5G PoE++ Managed Switch*

CategoryItemSpecification
OverviewDescriptionA high-performance hybrid PoE++ managed switch featuring 24 multi-rate (10M/100M/1G/2.5G) PoE ports and 6x 10G uplinks. With a 370W PoE budget and the last 8 ports supporting 802.3bt up to 60W, it's designed to power high-wattage APs, PTZ cameras, and high-power IoT terminals.
Physical SpecsPerformance

• Switching Capacity240 Gbps

• Forwarding Rate178.56 Mpps

• MAC Address Table32K

Hardware

• Flash Memory128 MB

• DRAM4 GB

Power

• InputAC 100-240V， 50/60 Hz

• Power Consumption75 W
InterfaceData Ports24 x 10/100/1000/2500Base-T PoE++ RJ45 Ports
6 x 1G/10G SFP+ Fiber Ports

Management Ports1 x Console (RJ45)
PoEStandard & Port ConfigPorts 1-16: IEEE 802.3af/at (Max. 30W per Port)
Ports 17-24: IEEE 802.3bt (Max. 60W per Port)

Total Power Budget370 W

Simultaneous PowerAll 24 Ports @ 15.4W (802.3af)
or 12 Ports @ 30W (802.3at)
or 6 Ports @ 60W (802.3bt)
Software FeaturesSystem ManagementSNMP， CLI， Web， SSH， ISDP， LLDP， Timer Schedule

Layer 2 SwitchingVLAN (4K), STP, LACP (12 groups， up to 8 ports/group), Loop Protection, Multicast, UDLD

VLANPort-based VLAN, Voice VLAN, Protocol VLAN, GARP, 802.1Q Tunneling

Quality of Service8 Queues per Port, Ingress/Egress Rate Limiting, Auto QoS, DiffServ

SecurityPort Authentication, ACL, Access Control, Traffic Control, DoS Protection

Maintenance & MonitoringsFlow, Port Mirroring, Logging, Configuration File Management, Upgrade
EnvironmentalOperating Temperature0°C to 40°C

Storage Temperature-20°C to 70°C

Operating Humidity20% to 85% RH (Non-condensing)

Storage Humidity5% to 95% RH (Non-condensing)

CoolingForced Air Cooling
MechanicalDimensions (W×H×D)440 mm × 44 mm × 330 mm (1U)

Weight5 kg


HODONET S3000-24M6XF-PoE++, 24-Port 2.5G PoE++ Managed Switch (with 6x 10G SFP+ Slots)

The HODONET S3000-24M6XF-PoE++ is a hybrid PoE++ managed switch designed for dense access scenarios involving high-power, high-bandwidth devices. It innovatively divides its 24 x 2.5G PoE++ ports into two groups: the first 16 ports support 802.3af/at standards (up to 30W per port), while the last 8 ports further support the 802.3bt standard (up to 60W per port), delivering a total PoE power budget of up to 370W. This enables it to power not only standard wireless APs and cameras but also directly drive high-power PTZ cameras, digital signage, smart building control panels, and even some industrial IoT devices, truly achieving "one cable for all." Coupled with six 10G SFP+ uplink ports, it ensures high-speed aggregation of massive data flows. Equipped with comprehensive Layer 2 management and quality of service features, this switch is the ideal core for building a unified access platform that converges data, voice, video, and high-power device power delivery in demanding environments such as enterprise campuses, smart factories, large shopping malls, and transportation hubs.
